Description

Integrated conductivity probe ensures precise detergent concentration by continuously monitoring water conductivity.

Dual‑pump system

Doses detergent and rinse aid for commercial dishwashers.

Powerful microprocessor control

Provides intuitive programming via LED interface.

Auto‑calibration technology SEKO’s patented system adjusts dosing based on probe feedback to maintain consistent concentration.

Optional built‑in Wi‑Fi

Allows remote monitoring, wash statistics, and chemical consumption data via SekoWeb or smartphone app.

Detergent pump flow rate: 1.4 – 9 L/h (Santoprene tubing)

Rinse‑aid pump flow rate: 0.2 – 1.5 L/h (SekoBril tubing)

Supports 3 dosing modes:
Probe mode: Uses conductivity probe to maintain detergent concentration
Probeless mode: Time‑based detergent dosing
Simplified mode: Patent‑pending, restores target conductivity after initial fill

Voltage: 240 V (AU configuration)

Ingress protection: IP65 (dust‑tight and water‑resistant)

Electrical insulation: Class II

Flexible power supply: 100–240 Vac @ 50/60 Hz

Accepts up to 3 machine signals:
First charge solenoid valve
Rinse solenoid valve
Wash pump signal
(Voltage 12–230 Vac selectable via jumpers)

Modbus interface for external system integration

Over‑feed alarm if conductivity not reached in set time

Compact, robust polished‑white casing suitable for food‑service environments

Quick‑connect transport tubes (6 mm O.D.) for faster, safer installation

Enhanced chemical‑resistant POE tubing included

Installation Kit:
Conductivity probe
Detergent injector
Rinse non‑return valve
Power cable
Blue PVC detergent tubing (4 m roll)
PVC/PE rinse aid tubing (2 m inlet + 2 m outlet)
